Specfication
Model
Travel
LT-350
LT-400
LT-520
X-axis
mm
140
180
220
Z-axis
350
530
710
Spindle
Spindle speed
RPM
40-6000
30-4000
30-3500
Spindle nose
A2-5
A2-6
A2-8
Front bearing inner dia.
80
100
130
Thru-hole dia.
56
63
88
Capacity
Swing over bed
400
520
Swing over slide
280
320
Center distance
455
645
845
Standard turning dia.
174
216
Max turning dia.
240
Max turning length
Bar capacity
45
52
78
Turret
No. of station
12- Vị trí
12-Vị trí
10-Vị trí
Size of holder(sq
20
25
Boring holder dia
32
40
50
Tailstock
290
435
580
Quill stroke
150
Size of taper
MT4
MT5
Quill I.D.
75
90
110
Feedrate
X-rapid
M/mm
24
Z-rapid
30
Motor
Spindle motor
kw
7.5/11
15/18.5
X-servo motor
1.2
1.6
Z-servo motor
1.8
2.5
3.0
Turret-servo motor
0.75
Controller
Fanuc
0i MATE-TD
Machine size
Weight
kg
3500
4300
5000
Width
1885
2250
2850
Height
1720
1770
1895
Depth
1600
1670
1800
Miscellaneous
Power requirement
KVA
15
Air source
kg/cm2
6
Coolant capacity
L
160
200
230
Controller capacity
Display
8.4" inch color LCD
Graphic
Yes
Full key
44
Max program storage length
320m
Max program no
No. of tool compenstation
64
Sever HRV control
HRV2 (3)
Interactive program
Manual Guide Oi
Sevo motor
Sevo spindle
Βis
βi
α i
Running time & worpiece counter
Auto power off
Macro B
RS-232 port
Memory card I/O interface
